Parasounf HALO JC 1+ Dual Mono Block 400W RMS /8 Ω

Parasounf HALO JC1+ Monoblock 400W RMS /8 Ω

Кратко описание:

High End висок клас едноканален усилвател с безкомпромисен саунд и изключително представяне работещ и в Class A 25W мощност.
Изграден на базата на двоен моно дизайн с два трансформатора с изключително разделяне на каналите и звукова точност.
Директното свързване, без кондензатори по пътя на сигнала, запазва максимално вида и целостта на входния сигнал и подобрява точността, прозрачността и сцената.
Проектиран от легендата в бранша John Curl

Цена: 21499 лв. / 10992.26 €

Доставка и плащане Рекламации Защита на лични данни

  • Premier monaural amplifier
  • Circuitry designed by legendary John Curl and CTC Builder
  • Ultra-high bias Class A/AB operation
  • Exclusive two position bias level adjustment
  • Balanced inputs with discrete circuits and XLR connectors
  • Vampire Direct gold-plated OFC RCA input
  • Dual heavy-duty 24k gold-plated 5-way speaker binding posts
  • Direct Coupled - no capacitors or inductors in signal path
  • Complementary MOSFET driver stage and JFET input stage
  • 18 beta-matched 15 amp, 60 MHz bipolar output transistors
  • 1.9 kVA encapsulated toroid power transformer
  • Independent power supplies for input, driver and output stages
  • 18,000 μF filters for driver stage
  • 132,000 µF Nichicon Gold Tune filters for output stage
  • DC Servo and relay protection circuits
  • REL and Nichicon Muse capacitors
  • Harris hyper-fast soft recovery diodes for all bridge rectifiers
  • Auto turn-on by 12v trigger or audio signal trigger
  • Ground lift switch , adjustable turn-on delay
  • 4u Chassis with rear carry handles, rack mounting kit included
  • Premium detachable AWG 12 power cord with silver solder
  • THX Ultra2 certified
Continuous power output, 20Hz - 20 kHz:
  • 400 W RMS x 1, 8 Ω
  • 800 W RMS x 1, 4 Ω
  • 1200 W RMS x 1, 2 Ω
Class A power output, 20Hz - 20 kHz:
  • 25 W, bias set to high
  • 10 W, bias set to low
Current capacity: 135A peak
Power bandwidth: Hz - 120 kHz, +0/-3 dB at 1 watt
Total harmonic distortion:< 0.15 % at full power
IM distortion: balanced 16 V rms: < 0.03%
S/N ratio:       >120 db, IHF A-weighted, bias set to high
                     >122 dB, IHF A-weighted, bias set to low
Slew rate:> 130 V/µsecond

Dynamic headroom: > 1.8 dB
Input sensitivity:1 V for 28.28 V, THX Reference Level
Input impedance:100 k Ω
Damping factor: > 1200 at 20 Hz

Power Requirement:
       250 W idle
     1280 W full power into 4 Ω
DC trigger output capacity:12 Vdc, 150 mA

Dimensions: 17-1/2" w x 7-5/8" h x 20" d, 7" h without feet

Net weight: 29.5kg
